Wide format digital printing sublimaiton paper machine F3208
Epson i3200-A1 eight head
Print Speed: 1PASS 370㎡/h 2PASS 200㎡/h
Product Features:
1. heavy-duty all in one machine
2. Adjustable pinch roller
3. Silent guide rail
4. air shaft feed up and take up system
5. High precision platform
Technical Parameters:
|
Printer Model |
F3208 |
Interface |
USB3.0 |
|
Print Width |
3200mm |
Rip Software |
RIIN, MainTop |
|
Print Head |
Epson i3200-A1 eight head |
Working Voltage |
AC220V |
|
Print Speed |
1PASS 370㎡/h |
Working environment |
Temperature:15-30℃ Humidity:40-60% |
|
Ink Type |
Environmentally friendly high-concentration thermal transfer dispersion ink |
Host size |
4844 x1340x1635mm |
|
Material handling |
Air shaft feed up and take up system |
Package size |
4894 x1390x1825mm |
|
Roll specifications |
3.2m width, 250mm diameter, weighing approximately 1200KG |
Power |
Rated power 2.5KW, Heating power 12KW |
|
Ink bucket configuration |
3.5L*4pcs |
Equipment weight |
1100KG |
Widely format multi-head high speed
