Hefei Laiou

Make printing easy

F3216

Wide format digital printing sublimaiton paper machine F3216



Epson i3200-A1 sixteen head
Print Speed: 1PASS 760㎡/h 2PASS 380㎡/h
Product Features:
1. Magnetic levitation linear motor

2.Paper feeding without pressure roller rubber roller

3.Silent linear quide ral

4.10000 meters retractable system
5. High precision platform



Technical Parameters:

Printer Model

F3216

Interface

USB3.0

Print Width

3200mm

Rip Software

RIIN, MainTop

Print Head

Epson i3200-A1 sixteen head

Working Voltage

AC380V

Print Speed

1PASS 760㎡/h

Working environment

Temperature:15-30℃ Humidity:40-60%

Ink Type

Environmentally friendly high-concentration thermal transfer dispersion ink

Host size

5660 x1190x1790mm

Material handling

Air shaft feed up and take up system

Package size

3771 x1110x1170mm

Roll specifications

3.2m width, 800mm diameter, weighing approximately 1200KG

Power

Rated power 18KW, Lower drying 380V/7.KW

Front drying 220V/4.8KW

Ink bucket configuration

15L * 4pcs

Equipment weight

2700KG



Epson I 3200-A1 sixteen head
Widely format multi-head high speed
