Wide format digital printing sublimaiton paper machine F2216
Epson i3200-A1 sixteen head
Print Speed: 1PASS 680㎡/h 2PASS 340㎡/h
Product Features:
1. Magnetic levitation linear motor
2.Paper feeding without pressure roller rubber roller
3.Silent linear quide ral
4.10000 meters retractable system
5. High precision platform
Technical Parameters:
|
Printer Model |
F2216 |
Interface |
USB3.0 |
|
Print Width |
2200mm |
Rip Software |
RIIN, MainTop |
|
Print Head |
Epson i3200-A1 sixteen head |
Working Voltage |
AC380V |
|
Print Speed |
1PASS 680㎡/h |
Working environment |
Temperature:15-30℃ Humidity:40-60% |
|
Ink Type |
Environmentally friendly high-concentration thermal transfer dispersion ink |
Host size |
4520 x1410x1850mm |
|
Material handling |
Air shaft feed up and take up system |
Package size |
2800 x1310x1200mm |
|
Roll specifications |
2.2m width, 800mm diameter, weighing approximately 1000KG |
Power |
Rated power 14KW, Lower drying 380V/6KW Front drying 220V/3.2KW |
|
Ink bucket configuration |
15L * 4pcs |
Equipment weight |
1800KG |
Industrial design high quality and efficiency
